DrayTek Vigor2862ac
VDSL2/ADSL2+ Multi WAN Firewall QoS IPv6 Router, Gigabit, and 3G/4G USB WAN port for Load Balancing and Fail-over, 4 x Giga LANs, CSM, 32 x VPNs, 16 x SSL VPNs, 802.11ac (AC2000), and support Smart Monitor (30 nodes) & VigorACS SI
$549.00

Product Availability: Stock reports there should be medium level quantities in store at this time. To reserve stock please place an order online (*no* payment details or commitment required to place order online, but please only order if you plan on getting it (stock availability dependent)).


Vigor2862 Series

VDSL2 & ADSL2+ Dual-WAN Security Router
  • VDSL2/ADSL2+ Router
  • 802.11ac Wave 2 dual-band wireless for speed up to 1.7Gbps (ac/Vac model)
  • 1 Ethernet WAN for Load Balancing or Failover
  • 2 USB ports for 3G/4G modem or extra storage
  • 32 Simultaneous VPN Tunnels
  • SPI Firewall with Content Filtering
  • Central Management for VigorAP & Vigor Switch

Hardware

  • 1 x ADSL2/VDSL2, RJ-11 (WAN-1)
  • 1 x 10/100/1000Base-TX, RJ-45 (WAN-2) (for standard )
  • 4 x 10/100/1000Base-TX LAN, RJ-45, Configurable Physical DMZ on Port4
  • 2 x USB Host 2.0
  • 1 x Factory Reset Button
  • 2 x Detachable Antennas (n/Bn model)
  • 4 x Detachable Antennas (ac/Vac model)
  • 1 x Wireless On/ Off/ WPS Button  (n/Bn/ac/Vac model)
  • Dimension : L241*W165*H44 (mm

Wi-Fi Frequency

11b/g/n :

  • 2.412 ~ 2.462GHz (USA)
  • 2.412 ~ 2.472GHz (Europe ETSI)

11a/n/ac :

  • 5.150 C 5.250 & 5.725 C 5.825 GHz (USA)
  • 5.150 C 5.250 & 5.470 C 5.725GHz (Europe ETSI)

Wireless Transmit Power

  • 2.4GHz Max : 19 dBm
  • 5 GHz Max : 29 dBm

Operating Requirement

  • Operating : 0C ~ 45C
  • Storage : -25C ~ 70C
  • Humidity : 10% ~ 90% (non-condensing)
  • Power : DC 12V @ 1.5A ~ 2A
  • Power Consumption19~24 watt

ADSL

  • ANSI T1.413 (ADSL)
  • ITU G.992.1 G.dmt (ADSL)
  • ITU G.992.2 G.lite (ADSL)
  • ITU G.992.3 (ADSL2)
  • ITU G.992.3 Annex M/J (ADSL2)
  • ITU G.992.5 (ADSL2+)
  • AITU G.992.5 Annex M/J (ADSL2+)



VDSL

  • ITU G.993.1 (VDSL), ITU-T G997.1
  • ITU G.993.2 (VDSL2)
  • VDSL Band Plan: 997, 998
  • VDSL2 Profile: 8a, 8b, 8c, 8d, 12a, 12b, 17a, 30a



WAN

  • Support fallback to ADSL2/2+ when fail to connect in VDSL2
  • xDSL WAN
    • DHCP Client
    • Static IP
    • PPPoE (and pass through)
    • PPPoA
    • MPoA
    • 802.1p/q VLAN Tagging
    • Default VLAN/PVC profile by region
  • Giga Ethernet WAN
    • DHCP Client
    • Static IP
    • PPPoE
    • PPTP
    • L2TP
    • 802.1q VLAN Tagging
  • USB WAN
    • Support PPP / DHCP mode (for 3G/4G)



Dual WAN

  • Load Balance and Route Policy : 50 profiles
  • WAN connection failover
  • Multiple-VLAN



LAN

  • Support IPv6 LAN
  • Port-based / Tag-based VLAN
  • Bind IP to MAC Address
    • Disable / Enable / Strict Bind
    • IP Bind list: 1024 entries
  • LAN Port Mirror
  • Wired 802.1x
  • Web Portal
  • Support IP Pool Count more than 253 (up to 1022) for LAN1~3 subnet
  • 8 x Multiple Subnet LAN



Firewall

  • NAT
    • DMZ Host (for DSL / GbE / Backup WAN)
    • Port-Redirection (40 profiles)
    • Open Port (40 profiles)
    • Port Trigger (20 profiles)
  • Object-based Firewall (v3)
  • SPI (Stateful Packet Inspection) (Flow Track)
  • DoS Defense
  • E-Mail alert (DoS Attack/APPE) and logging via syslog
  • Time Schedule Control
  • User Management
    • User-based / Rule-based
    • Up to 200 Profiles
    • Support external authentication by LDAP/RADIUS/TACACS+
    • Support Data-base & Time-base Quota
    • Schedule Control to delete or disable account automatically



CSM

  • Service Activation Wizard
  • APP Enforcement (IM/P2P Application v3)
    • Up to 32 Profile
    • APPE Signature Upgrade
  • URL ContentFilter :
    • URL Access Control (Keyword Blocking)
    • Pass / Block Web Feature(Cookie, Proxy, Upload File extension)
    • Support File Extension Object: Image, Video, Audio, Java, Active X, Compression, Execution, P2P
  • WEB Content Filter
    • Service activation wizard in main bar
    • Support Cyren / BPjM
    • White/Black list for Keyword Object/Group
  • DNS Filter for WCF/UCF



VPN

  • 32 Simultaneous VPN
  • Protocol: PPTP, IPsec, L2TP, L2TP over IPsec
  • Encryption: MPPE and Hardware-based AES/DES/3DES
  • Authentication: MDS, SHA-1
  • IKE Authentication: Pre-shared Key and Digital Signature (X.509)
  • LAN-to-LAN, Teleworker-to-LAN(Remote Dial-in User)
  • DHCP over IPSec
  • IPSec NAT-Traversal (NAT-T)
  • Dead Peer Detection (DPD)
  • VPN Pass-Through
  • VPN Wizard
  • mOTP
  • SSL VPN : 16 Tunnels
  • Support TLS/SSL Encryption v3.0
  • VPN Trunk with Load Balance / Backup



Routing

  • Static Route (IPv4 up-to 30 entries / IPv6 up-to 40 entries)
  • RIPv2
  • Policy-based Routing
  • Inter-VLAN Routing



Bandwidth Management

  • Bandwidth Limitation
  • Session Limitation (Up to 20 lists)
  • QoS (Quality of Service)
    • Guaranteed bandwidth for VoIP
    • Class-based Bandwidth Guaranteed by user-defined traffic categories
    • DiffServ Code Point classifying
    • 4-level priority for each direction (Inbound/Outbound)
  • Layer-3 (TOS/DSCP) QoS Mapping
  • APP QoS



Central Management

  • AP Management: 20 (independent with External Device feature)
  • VPN Management : 8
  • External Devices : 30



Network Feature

  • Packet Forwarding Acceleration (Default is disabled)
  • DHCP Client/Relay/Server
  • DHCP Option: 1,3,6,51,53,54,58,59,60,61,66,125
  • IGMP Proxy V2/V3
  • IGMP Snooping
  • Dynamic DNS
  • LAN DNS / DNS Forwarding
  • DNSSEC
  • NTP client
  • Call Scheduling
  • RADIUS / TACACS+ client
  • Internal RADIUS server
  • Active Directory /LDAP compatible (client)
  • DNS Cache/Proxy
  • UPnP 50 sessions
  • Wake on LAN
  • Bonjour service
  • Support SmartMonitor (Up to 30 PCs)



System Management

  • Web-based user interface (HTTP/HTTPS)
  • Quick Start Wizard
  • Dashboard
  • CLI (Command Line Interface, Telnet/SSH)
  • Administration access control
  • Login Page Greeting
  • Configuration backup/restore
  • Built-in diagnostic function
  • Firmware upgrade via TFTP/FTP/HTTP/TR-069
  • Logging via syslog
  • SNMP V2/V2c/V3
  • Data Flow Monitor
  • Support SMS/E-mail Alert
  • External Device (Master Mode)
  • TR-069
  • TR-104
  • Support Multi-Firmware Upgrade Utility
  • Two-level management (admin/user mode)



USB

  • Printer Sharing
  • File System
    • Support FAT32 file system
    • Support FTP function for file sharing
    • File explorer
    • Support Samba for file sharing (DrayTeks own SMB protocol stack)
  • Support USB Temperature Sensor
  • Support USB Device Status for Disk, Modem, Printer and Sensor
  • 3.5G (HSDPA) and 4G (LTE) as WAN3/WAN4 by using USB dongle



Wireless AP  (n/Bn/ac/Vac model)

  • Support Single 2.4G (n/Bn model)
  • Support Simultaneous 2.4G/5G Dual-Band (ac/Vac model)
  • Auto channel selection
  • Multiple SSID
  • Hidden SSID
  • Wireless LAN Isolation
  • Wireless Rate-Control
  • 64/128-bit WEP
  • WPA/WPA2
  • MAC Address Access Control (Total 64 entries)
  • WPS
  • WDS (Wireless Distribution System)
  • WMM
  • Access Point Discovery
  • 802.1x Authentication
  • Station List / Control
  • Wireless Wizard
  • SSID VLAN grouping with LAN port (Port-based VLAN)



VoIP  (Vac model)

  • Protocol: SIP, RTP/RTCP
  • VoIP Wizard
  • VoIP Status
  • 12 SIP Registrars
  • G.168 Line Echo-cancellation
  • Automatic Gain control
  • Jitter Buffer
  • Voice codec:
    • G.711
    • G.723.1
    • G.726
    • G.729 A/B
    • VAD/CNG
  • DTMF Tone :
    • Inband
    • Outband (RFC-2833)
    • SIP Info
  • FAX/Modem Support :
    • Tone Detection
    • G.711 Pass-through
    • T.38 for FAX
  • Supplemental Services :
    • Internal Call (dial 10 or 20 for Phone 1 or Phone 2. Only for
      debug usage)
    • Call Hold/Retrieve/Waiting
    • Call Waiting
    • Call Waiting with Caller ID
    • Call Transfer
    • Call Forwarding (Always, Busy and No Answer)
    • CLIR (Calling Line Identification Restriction)
    • Call Barring (Incoming/Outgoing)
    • DND (Do Not Disturb)
    • MWI (Message Waiting Indicator) (RFC-3842)
    • Hotline
    • ZRTP
  • PSTN Loop-through When Power Failure
  • Dial Plan :
    • Phone Book
    • Digit Map
    • Call Barring
    • Regional
    • PSTN Setup



For more information, please visit this webpage.
This product was added Thursday 09 November, 2017.
This product was last modified on Thursday 14 November, 2019.
