Noctua NH-D14
CPU Cooler: 775, 1156, 1155, 1151, 1150 1366, AM2,AM2+,AM3, ultimate quiet
$113.00

Product Availability: Stock reports there should be low level quantities in store at this time. To reserve stock please place an order online (*no* payment details or commitment required to place order online, but please only order if you plan on getting it (stock availability dependent)).

Combining a massive six heatpipe dual radiator design with an exquisite NF-P14/NF-P12 dual fan configuration, the NH-D14 is built for ultimate quiet cooling performance. Topped off with a tube of Noctua��s award-winning NT-H1 thermal compound as well as the new SecuFirm2 multi-socket mounting system, the NH-D14 is an elite choice for the highest demands in premium quality quiet cooling.

Providing more surface area, better heat-distribution and superior airflow efficiency than conventional tower style heatsinks, the NH-D14��s six heatpipe dual radiator design was developed to provide ultimate quiet cooling performance in dual fan mode. The NH-D14 sports a premium quality dual fan setup consisting of Noctua��s award-winning NF-P12 (120mm) and NF-P14 (140mm) fans, both of which feature Vortex-Control Notches, SCD technology and SSO-Bearings in order to achieve a perfect balance of performance and quietness. An asymmetrical design that gives more clearance towards the RAM slots ensures good compatibility despite the cooler��s size. The NF-P12 fan can be moved upwards or left in order to further improve compatibility. Hanging out at the bottom of the fin-stacks, the NF-P14 fan doesn��t only contribute to the NH-D14��s superb CPU cooling capabilities but also provides massive airflow over surrounding motherboard components and heatsinks, thus ensuring excellent component cooling performance. Noctua��s enthusiast grade SecuFirm2 multi-socket mounting provides broad socket compatibility (LGA1366, LGA1156, LGA775, AM2, AM2+ and AM3) and meets the highest demands in safety, contact pressure and ease-of-use.




Socket compatibility
Intel LGA1366, LGA1156, LGA1155, LGA1151, LGA1150, LGA775, LGA2011 on request, Asus X-socket™ & AMD AM2, AM2+, AM3, AM3+, FM1, FM2, FM2+ (backplate required)



Height (without fan)
160 mm



Width (without fan)
140 mm



Depth (without fan)
130 mm



Height (with fan)
160 mm



Width (with fan)
140 mm



Depth (with fan)
158 mm



Weight (without fan)
900 g



Weight (with fan)
1070/1240* g



Material
Copper (base and heat-pipes), aluminium (cooling fins), soldered joints & nickel plating



Application
see TDP guide



Fan compatibility
140x150x25 (with 120mm mounting holes), 140x140x25 (with 120mm mounting holes), 120x120x25



Scope of Delivery
  • 1x NF-P14 premium fan
  • 1x NF-P12 premium fan
  • 2x Ultra-Low-Noise Adaptor (U.L.N.A.)
  • Y-Split Cable
  • 4x Vibration-Compensators (for using NF-P12 as case fan)
  • 4x Fan screws (for using NF-P12 as case fan)
  • NT-H1 high-grade thermal compound
  • SecuFirm2™ Mounting Kits
  • Noctua Metal Case-Badge



  • Warranty
    6 Years





    Fan specifications





    Model
    Noctua NF-P14 & Noctua NF-P12



    Bearing
    SSO-Bearing



    Rotational Speed (+/- 10%)
    1200 / 1300 RPM



    Rotational Speed with U.L.N.A. (+/- 10%)
    900 / 900 RPM



    Airflow
    110,3 / 92,3 m³/h



    Airflow with U.L.N.A.
    83,7 / 63,4 m³/h



    Acoustical Noise
    19,6 / 19,8 dB(A)



    Acoustical Noise with U.L.N.A.
    13,2 / 12,6 dB(A)



    Input Power
    1,2 / 1,08 W



    Voltage Range
    12 V



    MTBF
    > 150.000 h
    For more information, please visit this webpage.
    This product was added Saturday 02 January, 2010.
    This product was last modified on Tuesday 12 November, 2019.
